Specifications

Rated Output

2.0mV/V±1%

Zero Balance

±1%F.S

Comprehensive Precision

0.03%F.S

Input Impedance

380±5Ω

Linearity/ Hysteresis

±0.03%F.S

Output Impedance

350±3Ω

Repeatability

±0.03%F.S

Insulation Impedance

≥5000MΩ

Creep

±0.03%F.S/30min

Recommended Excitation Voltage

5～15V/DC

Temp. Effect On Zero

±0.03%/10℃

Compensated temp. Range

-30℃～+70℃

Temp. Effect On Output

±0.03%/10℃

Safe Overload

150%F.S

Connection

Excitation：+ Red - Black        Shield： Thick Yellow

Signal： + Green - White
